Analytical Instrument Documents

This primer article introduces a practical guide for setting up 1H detection solid-state NMR experiments under fast MAS conditions for small molecules.

September 2024 Edition.

The JMS-S3000 SpiralTOF™-plus Ultra-High Mass Resolution MALDI-TOFMS System time-of-flight optics design utilizes a figure-eight ion trajectory to allow a 17m flight path to fit in an extremely small console.

Magic angle spinning (MAS) nuclear magnetic resonance (NMR) experiments at ultra low temperature (ULT) ( 100 K) have demonstrated clear benefits for obtaining large signal sensitivity gain and probing spin dynamics phenomena at ULT. ULT NMR is furthermore a highly promising platform for solid-state dynamic nuclear polarization (DNP). However, ULT NMR is not widely used, given limited availability of such instrumentation from commercial sources. In this paper, we present a comprehensive study of hydrated [U-C]alanine, a standard bio-solid sample, from the first commercial 14.1 Tesla NMR spectrometer equipped with a closed-cycle helium ULT-MAS system. The closed-cycle helium MAS system provides precise temperature control from 25 K to 100 K and stable MAS from 1.5 kHz to 12 kHz. The C CP-MAS NMR of [U-C]alanine showed 400% signal gain at 28 K compared with at 100 K. The large sensitivity gain results from the Boltzmann factor, radio frequency circuitry quality factor improvement, and the suppression of its methyl group rotation at ULT. We further observed that the addition of organic biradicals widely used for solid-state DNP significantly shortens the H T1 spin lattice relaxation time at ULT, without further broadening the C spectral linewidth compared to at 90 K. The mechanism of H T1 shortening is dominated by the two-electron-one-nucleus triple flip transition underlying the Cross Effect mechanism, widely relied upon to drive solid-state DNP. Our experimental observations suggest that the prospects of MAS NMR and DNP under ULT conditions established with a closed-cycle helium MAS system are bright.

High-capacity Li1+x(Ni0.3Mn0.7)1-xO2, (0 < x < 1/3) samples were synthesized by the coprecipitation–calcination method. Both electrochemical cycle and high-rate performances were drastically improved by selecting an N2 atmosphere as final calcination. Scanning transmission electron microscopy—energy dispersive X-ray spectroscopy analysis showed that the sample calcined in an N2 atmosphere had a more homogeneous transition metal distribution into primary particles than that calcined in air. The solid-state 7Li nuclear magnetic resonance data showed that electrochemically inactive domains were only diminished for the sample calcined in an N2 atmosphere after electrochemical activation. X-ray Rietveld analysis revealed that the suitable transition metal distribution and content of the samples were different from those of typical layered rock-salt materials. Only that calcined in an N2 atmosphere had no spinel formation during charging and no oxide ion insertion reaction during discharging. No positive Co substitution effect was observed under the optimized preparation conditions. At the 100th cycle, the discharge capacity was 216 mAh g−1, which corresponds to 87% of the initial capacity (251 mAh g−1) at optimizing synthetic condition.

Polymers can be degraded by the effects of light, oxygen, heat, etc. so it is important to understand how the polymer structures change during degradation. Pyrolysis gas chromatograph quadrupole mass spectrometer (Py-GC-QMS) and matrix-assisted laser desorption/ionization time-of-flight mass spectrometer (MALDI-TOFMS) are powerful tools for analyzing polymeric materials. Py-GC-QMS is a method that instantaneously heats a sample with a pyrolyzer and then analyzes the pyrolysis products by GC-MS. Since most of the pyrolysis products are related to monomers and dimers, this technique allows for easy identification of the polymer substructures which is useful for identifying changes to the polymer when degradation occurs. MALDI-TOFMS involves a soft ionization technique that can directly ionize and analyze the intact polymer molecules and often produces singly-charged ions even for high molecular weight compounds. As a result, the m/z axis of the mass spectrum is equal to the mass of the ions, thus making it easy to interpret polymer distributions. Additionally, when MALDI is used with a high-resolution TOFMS, the accurate mass of each ion in the polymer series can be used to calculate their elemental compositions. Moreover, the molecular weight distribution of polymers can be calculated from the ion intensity distribution. In this work, we used Py-GC-QMS and high-resolution MALDI-TOFMS to evaluate the effects of UV irradiation on polymethyl methacrylate (PMMA).

The recent discovery of Na3LiTi5O12 (NTO), which possesses spinel symmetry (, #227) with the 8a site occupied by Na, has enabled investigations into the effect of the 8a-site cation on the physical properties of spinel titanates. Hence, in this study, the optical and photocatalytic properties of NTO were investigated and compared with those of spinel Li4Ti5O12 (LTO) and rutile TiO2. The bandgaps were estimated theoretically using hybrid density functional theory and experimentally using the ultraviolet–visible spectroscopy, and the obtained results were similar for both methods and spinel titanates. The valence- and conduction-band components of the spinel-type titanates were similar to those of other titanium oxides, and both NTO and LTO exhibited photocatalytic activity for sacrificial H2 evolution from water. However, although they have similar band structures and optical properties, the NTO photocatalytic activity was clearly lower than that of LTO. This can be attributed to the surface roughness and ease of defect formation in the NTO system, which hindered charge separation. These results indicate that the optical properties of spinel-type titanates can be tuned by replacing the cations at the 8a sites.

Analysis of complex mixtures with gas chromatography coupled with high-resolution time-of-flight mass spectrometry (GC-HRTOFMS) can produce a large amount of data. A new software program was recently reported that integrates all of the available mass spectrometric information from GC-HRTOFMS analysis into a concise report. New capabilities have now been added to the software to incorporate retention index data and to identify differences between two samples.

Solid-state NMR is a valuable tool for elucidating the structures and dynamics of materials at an atomic level. Proton multiple-quantum (MQ) /single-quantum (SQ) correlation NMR spectroscopy is widely used to probe spatial proximity among protons. In the triple-quantum (TQ)/SQ correlation experiment, the excitation of triple-quantum (TQ) coherences is traditionally achieved by a 90° pulse in conjugation with double-quantum (DQ) recoupling sequences. Nevertheless, such sequences often suffer from low TQ filtering efficiency and may lead to overlapping spinning sidebands in the indirect TQ dimension, especially at a slow MAS frequency. Herein, we design several supercycled symmetry-based RNnν γ-free TQ recoupling sequences and compare their performance via extensive numerical simulation and experiments. Experimental results further confirm that pulse sequence gives the highest TQ filtering efficiency of around 20% in the slow MAS regime (∼10 kHz). The 2D TQ/SQ spectrum at slow MAS is completely free of spinning sidebands in the TQ dimension due to its γ-free nature. We establish that such a γ-free pulse sequence is a superior candidate for TQ spectroscopy at slow MAS frequency.

Herein, a novel non-planar 2D COF with a stair-stepped structure was constructed from a Z-shaped building block for the first time. Compared with its similar planar COF, the unique stair-stepped non-planar COF possesses larger surface area and stronger fluorescence, which was further applied for specific explosive detection through a fluorescence quenching mechanism. This work not only extends the traditional planar 2D COF structures to unique non-planar structures based on the bottom-up design principle, but also expands the potential applications of COF materials.
